High Density Fused Tap Module

Features
Low Insertion Loss
High Density Tap Links (36 links in a 19 inch 1RU chassis)
Easy Installation with Magnet Fixture
Applications
Network Security Monitoring
Traffic Analysis


Parameters

Unit

Specifications

Operating Wavelength

nm

1310±20nm or 1550±20nm

1310/1550±20nm

Configuration

-

1x2

Split Ratio

dB

50:50

30:70

50:50

30:70

Insertion Loss

dB

3.6/3.6

2.0/6.1

3.7/3.7

2.0/6.1

PDL

dB

0.2

Return Loss

dB

≥45

Directivity

dB

≥50

Fiber Type

-

SMF-28e+

Connector / Adapter Type

-

LC/UPC, or MTP/UPC

Package Dimension

mm

165x138x18
